EIZO 69cm(27”) CS2740 black
3.499,00 KM
EIZO 69cm(27”) CS2740 black
The CS2740 displays images, videos and graphics exactly as it should – ultra-sharp, rich in detail, undistorted and precise. It offers full 4K UHD resolution for videographers, maximum sharpness for photographers, and absolute precision and rich colours for all. This allrounder from the CS series features a USB-C port which forms the visual core of any digital, colour-accurate workflow and guarantees consistent results with incredibly rapid, hardware calibration.
• IPS wide gamut panel with 3840 x 2160 pixels (4K-UHD) with LED technology,
• Contrast 1000:1
• Brightness of 350 cd/m2
• USB C, DisplayPort and HDMI ports
• Four USB downstream ports (2x USB 3.1, 2x USB 2)
• EIZO ColorNavigator calibration software available for free download
• Handle for simple transport
• Light protection shield with simple magnetic attachment available as an optional extra
• Five-year warranty with an on-site exchange service
Full 4K resolution for videographers – maximum sharpness for photographers
From photographers who make films to videographers who take photographs, right through to time-lapse photography and cinemagraphs – the borders between visual content are becoming visibly blurred, while also growing ever closer at the same time. Videographers want to see their material in the full 4K UHD resolution, while photographers wish to preview the full sharpness of their printed images on the monitor. The ColorEdge CS2740 from EIZO fulfils both these requirements down to a tee. An ultra-sharp monitor display is guaranteed with 3840 x 2160 pixels, which corresponds to a detail resolution of 164 ppi.
The ideal combination of wide gamut, utmost precision out of the box and ultrafast calibration
A graphics monitor’s most important task is to display exactly what the camera has saved. That’s why each ColorEdge CS2740 is individually measured and optimally configured in the factory. Inhomogeneities like differences in brightness and partial unnecessary colours are identified and permanently removed. The ColorEdge CS2740 is hardware-calibratable in just 90 seconds* without losses, which means that it consistently retains its factory-set perfection across its entire service life.
A processor developed by EIZO (ASIC) computes the necessary colour commands in the monitor with a 16-bit colour depth. The CS2740 covers all conventional gamuts (e.g., 99% AdobeRGB) for brilliant and differentiated reproduction, even for saturated colours. This allows further steps in the digital workflow like printing (in the soft-proofing view) to be simulated reliably.
Full port power with USB-C
A growing number of creative professionals are using their portable computers not just while they’re on the go. A powerful laptop is often their only computer, which is why more and more of them want to integrate their portable computer into their office at home or at work.
EIZO is supporting this trend with the new ColorEdge CS2740 graphics monitor. Thanks to its four downstream ports and its USB-C upstream port, hard disks, mice, keyboards and other peripheral devices such as memory card readers can be connected directly to the monitor. The user then only needs to connect the laptop to the CS2740 using just the one USB-C cable to integrate their portable computer into the entire workflow and to supply up to 60 watts of power. The need for a separate docking station or additional power supply unit is a thing of the past. Plus, the CS2740 also has HDMI and Display Port inputs. This makes the ColorEdge CS2740 the central hub for discerning creative professionals.
Ultrafast calibration
The EIZO ColorNavigator 7 calibration software can be downloaded free of charge from the EIZO website. When combined with the EIZO EX4 calibration sensor, the ColorEdge CS2740 is capable of calibrating in approx. 90 seconds.
The CH2700 light protection shield is available as an optional extra and can be simply attached and held in place magnetically without the need for adhesive or screws.
* Measured using EIZO EX4 and MacBook Pro
Technische Spezifikationen
https://www.eizo.eu/coloredge/cs2740
| Article no. | CS2740 |
| Housing colors | Black |
| Area of application | Photo, Design & Media |
| Product line | ColorEdge |
| EAN | 4995047055624 |
| Diagonal [in inches] | 26.9 |
| Diagonal [in cm] | 68.4 |
| format | 16:9 |
| Visible image size (width x height) | 596.2×335.4 |
| Ideal and recommended resolution | 3840 x 2160 (4K UHD) |
| Pixel density [ppi] | 164 |
| Supported resolutions | 3840×2160 (4K UHD), 2560×1600, 2560×1440, 1920×1200, 1600×1200, 1680×1050, 1280×1024, 1024×768, 800×600, 720×400, 64 0 x 480, 1080p (@ 60 Hz), 1080i (@ 60 Hz), 576p (@ 60 Hz), 480i (@ 60 Hz), 720p (@ 60 Hz), 1080p (@ 50 Hz), 1080i (@ 50 Hz), 720p (@ 50 Hz), 576p (@ 50 Hz), 1080p (@30/25/24Hz), 2560×1440 (@30Hz) |
| Panel technology | IPS (Wide Gamut) |
| Max. Viewing Angle Horizontal | 178° |
| Max. Viewing Angle Vertical | 178° |
| Displayable colors or grayscale | 1.07 billion colors (Display Port, 10 bit), 1.07 billion colors (HDMI, 10 bit), 16.7 million colors (Display Port, 8 bit), 16.7 million colors (HDMI, 8 bit), 16.7 million colors (DVI, 8 bit) |
| Max. color space | AdobeRGB (>99%), DCI P3 (>90%), sRGB (100%), ISO Coated V2 (>99%), Rec709 (100%), EBU (100%), SMPTE-C (100%) |
| Max. brightness (typical) [in cd/m2] | 350 |
| Max. dark room contrast (typical) | 1000:1 |
| Typical reaction time [gray-gray change] | 10ms |
| Max. refresh rate [ in Hz] | 60 |
| Backlight | LED |
| Hardware calibration of brightness, white point and gamma/EOTF | √ with separate measuring device |
| Colour palette / look-up table | 278 trillion colors / 16 bit |
| Digital Uniformity Equalizer (homogeneity control) | √ |
| Flicker-free | √ |
| I/P conversion (HDMI) | √ |
| Signal range extension (HDMI) | √ |
| Noise reduction (HDMI) | √ |
| HDCP decoder | √ |
| Preset color/grayscale modes | Adobe RGB, sRGB, 8x free modes for user selection |
| OSD language | de, en, fr, es, it, se, yes, zh |
| Setting options | Brightness, Contrast, Gamma, Color Saturation, Color Temperature, Hue, Signal Input, Resolution, OSD Language, Interpolation, DUE Priority |
| Button Guide | √ |
| Signal inputs | USB Type-C (DisplayPort Alt Mode, HDCP 1.3), Display Port (HDCP 1.3), HDMI (Deep Color, HDCP 2.2/1.4) |
| USB specifications | USB 3.1 Gen 1 |
| USB upstream ports | 1 x Type C (DisplayPort Alt Mode, power supply 60W max.), 1 x Type B |
| USB downstream ports | 4 x Type A (2 x USB 3.1 Gen 1, 2 x USB 2.0) |
| USB Type-C | √ |
| Graphic signal | DisplayPort, HDMI (YUV, RGB) |
| Horizontal/vertical frequencies | DisplayPort: 25.0 – 137 kHz, 23 – 61 Hz; HDMI: 15 – 135 kHz, 23 – 61 Hz |
| Automatic signal input detection | √ |
| Power consumption (typical) [ in watts] | 36 |
| Power consumption (maximum) [ in watts] | 168 |
| Max. power consumption in standby mode [in watts] | 1 |
| Power consumption with power switch off [in watts] | 0 |
| Energy efficiency class | B |
| Annual energy consumption [ in kWh] | 62 |
| Power supply | AC100-240V, 50/60Hz |
| Integrated power supply | √ |
| Dimensions (including base) (width x height x depth) [inmm] | 638×404-559×265 |
| Weight (including stand) [ in kg] | 1.3 |
| Rotatability (right/left) | 344° |
| Tilt front/back | 5° / 35° |
| Rotatability portrait/landscape format (pivot) | 90° |
| Max. height adjustment [ in mm] | 155 |
| Mounting options | VESA standard 100 x 100 mm |
| Test mark | CE, CB, TÜV/GS, TÜV Ergonomics tested (including ISO 9241-307), cTÜVus, TÜV/S, EAC, PSE, FCC-B, CAN ICES-3 (B), RCM, VCCI-B, CCC, RoHS, China RoHS, WEEE |
| Related software and other accessories via download | ColorNavigator, ColorNavigator Network (on request), ICC color profile |
| Additional scope of delivery | Power cable, signal cable DisplayPort – DisplayPort, USB/signal cable (USB Type-C – USB Type-C), quick start guide |
| Optional accessories | EX4 (colorimeter for ColorEdge monitor calibration), EIZO ScreenCleaner (for ideal cleaning without scratching), CH2700 (light protection hood for the CS2730, CS2731 and CS2740 monitors), HH200HS-K (HDMI connection cable for transmitting digital video and audio signals), TC-BRACKET3-BK (thin client bracket in black for the EIZO Flexstand 3 stand) |
| Warranty and service | 5 years including on-site exchange service * |
